Assembly
AVENTICS | ECS Actuator | R417002911–BDL–001–AA 29
English
1. Protect the POWER cables with circuit breakers as shown in
the following table. Please note that circuit breakers are not
included in the delivery.
2. Connect the POWER cable to the power jack (7, fig. 8) of the
Marex ECS Actuator.
7.2.4 Grounding
O Connect the grounding cable to the grounding screw of the
actuator (8, fig. 8) and to a grounding screw of the ship.
Proceed in the same way to connect other actuators if
applicable. The electrical connections are then complete.
7.3 Mechanical connection
Before providing the mechanical connection via the push/pull
cable, the function of the actuator (gearbox/throttle control) and
the automatic configuration (auto-config) must be carried out.
Follow the instructions in chapter 8, Commissioning.
Tabelle 9: Circuit breakers for POWER cables
12VDC 24VDC
Imax 10A 8A
Circuit breaker 30A 16A
