20 AVENTICS | ECS Actuator | R417002911–BDL–001–AA
7 Assembly
7.1 Installation conditions and installation site
The Marex ECS Actuator is designed for installation in the
engine room. Basically, it can be mounted in any position, but
the following requirements must be fulfilled:
W The mounting flanges must rest evenly on the wall or
ceiling.
W The three mounting points must provide secure hold of the
actuator.
W Bend the push/pull cable as little as possible when
connecting it to the adjusting lever of the throttle or gearbox.
NOTICE
Property damage due to improper installation or mounting
work
Improper installation can cause damage to property.
O The Marex ECS Actuator may only be installed by
AVENTICS or qualified personnel as specified in chapter
2.4.
O Install or uninstall the Marex ECS Actuator only if the
component and the system are powered off.
O Prepare mounting work carefully.
O Make sure there is enough space to mount the product
professionally.
O Choose an installation site which does not expose the
Marex ECS Actuator to splash water.
