10 Disassembly and replacement
Proceed as follows to dismantle the Marex ECS Actuator:
1. Switch Marex ECS off.
2. Make sure the Marex ECS Actuator is powered off.
3. Remove the electrical connections (6) and (7) and the
grounding cable (8) (fig 7).
4. Remove the push/pull cable (3) (fig. 19).
5. Loosen the mounting nuts. You may now remove the
Marex ECS Actuator.
6. If applicable, install a new Marex ECS Actuator by following
the steps described in chapter 7, Assembly.
CAUTION
Injury hazard and material damage due to unmaneuverable
boat
If you dismantle or replace the Marex ECS Actuator while the
boat is in motion, the ability to steer may be lost.
O Only dismantle the actuator if the boat is not in
operation.
NOTICE
Material damage due to applied supply voltage
Attaching and removing plugs and connectors under power
can destroy the component.
O Only perform assembly or disassembly work on
electrical connections if components and cables are
powered off.
