16 AVENTICS | ECS Actuator | R417002911–BDL–001–AA
Fig. 2: Overview operating and indicating elements (LEDs)
5.4 LEDs - modes of operation
Two LEDs are provided on the actuator to supply information on
its state of operation. Each LED has three modes of operation
which are combined to form a visual signal. In this document,
the LED modes are illustrated by the following symbols:
10 Rotary coding switch
11 Device status LED, green
12 Device status LED, red
13 Push-button S3
14 Slide switch S2
Table 6: LEDs - Modes of operation
Symbol Meaning
LED is off.
LED flashes.
LED is permanently on.
