Commissioning
32 AVENTICS | ECS Actuator | R417002911–BDL–001–AA
2. Mount the Marex ECS Actuator and establish the necessary
connections (see chapter 7, Assembly).
3. Switch the power supply on.
4. Loosen the screws (15, fig. 12) of the transparent cover
using a cross-tip screwdriver. Leave the screws in the holes
to avoid losing them. Turn the cover sideways.
5. Turn the rotary coding switch S1 (10, fig. 12) to define the
actuator’s function. Refer to table 10 for information on the
functions. See also the actuator’s type plate as shown in
fig. 3.
Table 10: Rotary coding switch S1, settings
No. Function
0No Function, delivery state
1 SINGLE: throttle
TWIN: throttle portside
2 SINGLE: gear
TWIN: gear portside
3Alternative
4Alternative
5 SINGLE: no function
TWIN: throttle starboard
6 SINGLE: no function
TWIN: gear starboard
7Alternative
8Alternative
9Alternative
