Model E1010 Indicator User Instructions 17
7 Menu Mode
The E1010 has two menus you can use to set up and test the indicator: the User menu
and the Supervisor menu. Both are explained below.
7.1 User Menu
l Use the User menu to do the following:
l Audit the number of configurations and calibrations performed
l See software information
l Display test
l Button test
l Serial port test
1. Access the User menu by pressing and holding the ESC key for 3-5 seconds.
PASS_ is displayed.
2. Key in the User menu password, 111, and press the ENTER key. Figure 7.1
shows the User menu items. Use the keys shown in the dotted box in Figure
7.1 to navigate through the menu and choose the items you want.
Figure 7.1 User menu
Specific instructions on the User menu appear in the section Indicator Diagnostics later
in the manual.
Press the ESC key to exit the menu.
