36 Model E1010 Indicator User Instructions
8.4.2 Sample Mode: Using Product to Set Target Weight
Follow these steps to setup and use the checkweigher function if sample mode is
enabled, where you set target weight based on an actual “product”:
1. Place a sample, of the correct weight, on the scale…
Weight is displayed.
2. Press the F1 key.
The target weight is captured, the indicator switches to net mode, the
display reads 0 and your indicator is ready to use as a checkweigher.
The target weight will be the same as your sample item and the target
will stay lit whenever an item’s weight is within ±1 division of the target
weight.
8.4.3 Performing a Checkweighing Weighment
1. With your target weight set, as described in one of the previous two sections,
place your item on the scale…
If the weight equals the acceptable value, the TARGET annunciator
lights. If the weight varies from the target value, upper or lower
segments may be lit and the weight will show a plus or minus weight
reading for the deviation from the target weight.
2. Repeat step 1 for all products of this weight.
8.4.4 Using Outputs
The output function in the checkweigher mode functions differently than in the other
applications. The outputs are controlled by the over, under and accept values. OP1
activates and its annunciator illuminates when the under condition is present. OP2
activates and its annunciator illuminates when the accept condition is present. OP3
activates and its annunciator illuminates when the over condition is present.
Output operation in checkweighing mode:
Outputs are OFF in gross zero band
Annunciators are OFF
TIU3 Relays are OFF
Outputs latch on for appropriate ABOVE, OVER and ACCEPT
Annunciators are ON
TIU3 Relays are ON
