40 Model E1010 Indicator User Instructions
8.6.1 Configuring Outputs
Follow these steps and the flowchart in Figure 8.3 to setup a recipe with three
ingredients:
1. With the indicator powered up, press and hold the SELECT key until…
OP1 is displayed.
2. Press the PRINT key to set the value for the output…
Key in a value and press the F1 key to accept the value. OP2 will be
displayed.
You can scroll through all three outputs by using the TARE and UNITS
keys.
3. Press the UNITS key…
OP2 is displayed.
4. Repeat steps 2 and 3 for each output. Press ESC key to return to normal
operation with the ingredients active. Indicator will automatically return to
normal weighing mode after OP3 value is entered.
5. To start a batch, push the F1 key.
Output operation in batching mode:
Before activation by recipe:
Outputs are OFF
Annunciators are OFF
TIU3 Relays are OFF
After activation by recipe:
Outputs are ON
Annunciators are ON
TIU3 Relays are ON
