42 Model E1010 Indicator User Instructions
8.7.1 Using Outputs
You can use the outputs function if so desired while in the Peak Weighing application.
Follow these steps to setup the outputs.
1. With the indicator powered up, press and hold the SELECT key until…
OP1 is displayed.
2. Press the PRINT key to see a value entry screen…
Press the PRINT key to accept the displayed value or key in a new value
and press the ENTER key to accept. OP2 will be displayed.
3. Repeat for the other outputs. You can skip the displayed output by pressing
the ESC key.
4. After OP3 has been set, or skipped, the indicator will automatically return to
normal weighing mode.
Output operation in peak mode:
Below Configured Value:
Outputs are ON
Annunciators are OFF
TIU3 Relays are ON
Above Configured Value:
Outputs are OFF
Annunciators are ON
TIU3 Relays are OFF
