14 Model E1010 Indicator User Instructions
4 Battery Information
This unit may contain a sealed rechargeable 6 volt, 3.0Ah, lead-acid battery. Life
expectancy of this battery is 3-5 years in standby use or:
• 180 charging cycles (approx.) if discharged 100%
• 400 charging cycles (approx.) if discharged 50%
• 1200 charging cycles (approx.) if discharged 30%
Battery life is 23 hours with one 350 ohm weight sensor and 15 hours with four 350 ohm
weight sensors. Recharge time from complete discharge is 14 hours while powered up
and in service (single loadcell). The AC power supply (AC mains supply) will charge the
battery as it powers the indicator.
Battery life conservation can be configured through the indicator’s Supervisor menu.
See Supervisor Menu on page 18. You can set the sleep timer to OFF, 1/2 hour, two
hours or four hours. Use the OFF setting If the battery is not installed.
It is important that the battery be kept fully charged, either by the preferred method of
float charging (i.e. keeping the unit permanently plugged into AC power supply) or by
charging for 24 hours every 40-50 days. If a longer period of storage is required and
float charging is not practical, the battery should be disconnected.
If the indicator is sealed for Weights and Measures purposes, disconnecting the battery
may not be possible. In this case the only option is to ensure that the indicator is
connected to the AC supply to keep the battery topped off.
The battery should never be stored in a discharged state as permanent damage will
occur.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the battery manufacturer’s instructions.
When the indicator goes to sleep you must press the ON/OFF switch to restart the
indicator.
