Model E1010 Indicator User Instructions 13
Battery level annunciator. If the unit is powered by AC, this
annciator will be lit.
Peak weight annunciator
Print annunciator lights when data is being sent to an external
device.
Custom unit of measure annunciator
Preset tare annunciator
Blank rectangle This blank annunciator will light when an accumulation is
occurring
Output 1 annunciator lights when the output 1 is active. There
are annunciators for Output 2 and 3 also.
Piece weight annunciator lights when the piece weight in a
counting application is displayed.
Count annunciator lights when count is displayed in the
counting application.
Total annunciator lights when displaying the total count in the
accumulator application.
Unit of measure annunciator shows the current unit of
measure.
Checkweighing annunciator lights during use of the
checkweiging application.
