12 Model E1010 Indicator User Instructions
There are annunciators that are located around the display window. These provide
information on indicator function. Each is described below:
Press the UNITS key to scroll through the available units of
measure while in normal operating mode. Units are enabled in
a password protected menu. (Contact your local supplier or
Avery Weigh-Tronix distributor for assistance.) Also acts as a
right arrow key when in the menu structure.
Press the F1 key to select application specific choices. Also
used to access PLU (Product Look Up) memory channels.
Press the C/CE key to clear entries.
Press the MODE key to scroll through the enabled applications.
The application name is briefly displayed when key is released.
Press the ESC key to escape a function or return to normal
operation mode. Press and hold to access the password
display for the menus.
Press the ENTER key to accept displayed choices.
Use the numeric keypad to enter values.
For example:
• ID entry
• Setpoint target entry
• Preset tare entry
• Password entry
To turn the unit on, press and hold the ON/OFF key until the
display turns on. To turn the unit off, press and hold the ON/
OFF key until the unit turns off.
Center of zero annunciator
Motion annunciator
Gross weight annunciator
Net weight annunciator
Tare annunciator
