Model E1010 Indicator Service Manual
Below Configured Value:
Outputs are ON
Annunciators are OFF
TIU3 Relays are ON
Below Configured Value:
Outputs are ON
Annunciators are OFF
TIU3 Relays are ON
Outputs are OFF in gross zero band
Annunciators are OFF
TIU3 Relays are OFF
Outputs are OFF until activated
by recipe
Annunciators are OFF
TIU3 Relays are OFF
(All outputs turn off when scale reaches recipe weight)
Below Configured Value:
Outputs are ON
Annunciators are OFF
TIU3 Relays are ON
Below Configured Value:
Outputs are ON
Annunciators are OFF
TIU3 Relays are ON
This completes the Service menu. Press the ZERO key to return to normal
weighing mode.
Output operation in
general weighing mode:
Output operation in
accumulation mode:
Output operation in
checkweighing mode:
Output operation in
batching mode:
Output operation in
counting mode:
Output operation in
peak mode:
Above Configured Value:
Outputs are OFF
Annunciators are ON
TIU3 Relays are OFF
Above Configured Value:
Outputs are OFF
Annunciators are ON
TIU3 Relays are OFF
Outputs latch on for appropriate
ABOVE, OVER and ACCEPT
Annunciators are ON
TIU3 Relays are ON
Outputs are ON when activated by
recipe
Annunciators are ON
TIU3 Relays are ON
Above Configured Value:
Outputs are OFF
Annunciators are ON
TIU3 Relays are OFF
Above Configured Value:
Outputs are OFF
Annunciators are ON
TIU3 Relays are OFF
