Model E1010 Indicator Service Manual
The next section of the Service menu is the OUTPUT submenu. See Figure
12. This menu lets you configure the outputs of the indicator.
OUTPUT submenu
Figure 12
OUTPUT submenu
Follow these steps to access and configure the inputs:
1. Access the Service menu. . .
CAL is displayed.
2. Press the UNITS key repeatedly until. . .
OUTPUT is displayed.
3. Press the PRINT key. . .
1 is displayed. This stands for output #1. You can scroll to each
output by using the UNITS key or TARE key. When you access
each output, by pressing the PRINT key, you enable or disable the
output by selecting ON or OFF.
4. Toggle between ON and OFF by using the UNITS key or TARE key and
press the ENTER key to accept the displayed choice. . .
OUTPUT is displayed.
5. Press the ZERO key and the indicator returns to normal weighing mode.
See the output/annunciator/TIU3 relay relationship for each application on the
following page.
Service Menu—OUTPUT submenu
To Next Page
