51
Model E1010 Indicator Service Manual
TEST submenu
(Test menu)
ABOUT
(Indicator information)
DISP
(Display test)
BUTTON
(Key test)
ADC
(Analog to Digital converter)
1. Enter the Supervisor men and press the UNITS key repeatedly until…
TEST is displayed. This menu lets you view indicator information
and test the scale, the display, keypad, serial port, inputs and
outputs.
2. Press the PRINT key…
ABOUT is displayed. Press the PRINT key then the UNITS key to
view the part number and revision level for the software found in
your indicator.
Press SELECT key to return to ABOUT.
3. Press the UNITS key…
ADC is displayed. This stands for the analog to digital converter
value in mV/Vs.
4. Press the PRINT key…
The mV/V value coming into the indicator from the scale is dis-
played. You can use the ZERO key to zero the mV/V reading. The
scale can then be tested for function and linearity.
5. Press the SELECT…
ADC is displayed.
6. Press the UNITS key…
DISP is displayed. This is the display test item.
7. Press the PRINT key to perform a dynamic test of the display. This
allows you to see any damaged areas of the display, which may require a
display replacement.
8. Press the ESC key to stop the dynamic test.
9. Press the UNITS key…
BUTTON is displayed. This is the keypad button test item.
10. Press the PRINT key to perform a button test. Each key you press will
be reflected on the display screen to confirm the button is functioning
correctly.
11. Press the ESC key to stop the button test.
BUTTON is displayed.
