6
Model E1010 Indicator Service Manual
Keys
The functions of the keys on the front panel are listed below.
Never press a key with any-
thing but your finger. Damage
to the overlay may result if
sharp or rough objects are
used.
Press the TARE key to perform a tare function. Also acts as a
left arrow key when in the menu structure.
Press the SELECT key to toggle between Gross, Tare, Net,
Count, Gross Accumulator, Net Accumulator, Transaction
Counter, Piece Weight, and Peak. This is dependent on the
current application. Also acts as an up arrow key when in the
menu structure. Press and hold to access the outputs function.
Press the ZERO key to zero the display.
Press the PRINT key to send information to a peripheral device
through one of the communication ports. Also acts as a down
arrow key when in the menu structure.
Press the UNITS key to scroll through the available units of
measure while in normal operating mode. Also acts as a right
arrow key when in the menu structure.
Press the F1 key to select application specific choices. Also
used to access PLU (Product Look Up) memory channels.
Press the C/CE key to clear entries.
Press the MODE key to scroll through the enabled applications.
The application name is briefly displayed when key is released.
Press the ESC key to escape a function or return to normal
operation mode. Press and hold to access the password
display for the menu structure.
Press the ENTER key to accept displayed choices.
