42 XR Series Installation Instructions
9 Time and Date (not available on XR 2000)
9 Time and Date (not available on XR 2000)
The XR remote display has a precision time clock that compensates for variable
temperature conditions. The battery on the Controller board (J22) provides back-up
power for this clock.
9.1 Set Time & Date
9.1.1 Adjust Time
1. Make sure Time is enabled in Configuration Mode (Parameter 3.0)
2. Press and hold the UP/TIME key.
3. Use the UP and DOWN ARROW keys to select the correct hour and press
ENTER.
4. Repeat for minutes and AM/PM if enabled (12 hour clock).
9.1.2 Adjust Date
1. Make sure Date is enabled in Configuration Mode (Parameter 3.1)
2. Press the DOWN/DATE key.
3. Use the UP and DOWN ARROW keys to select the correct year/month/day
(International) or month/day/year (USA) and press ENTER.
9.2 Battery / Battery Replacement
The XR displays use a 3 Volt lithium battery. Power is drawn from the battery only when
the unit is disconnected from AC power. If time and date are lost when the unit is
disconnected from AC power, the battery likely needs replacement.
1. Remove the old battery from the J22 terminal on the Controller board by hand.
2. Observe proper battery polarity before inserting new battery.
3. Ensure the battery is seated correctly in the J22 terminal.
CAUTION! Risk of explosion if battery is replaced by an incorrect type. Dispose
of used batteries according to their instructions.
CAUTION! Never use metal objects such as screwdrivers to remove batteries!
This may result in personal injury or damage to the unit.
