XR Series Installation Instructions 9
2.1 Display
2 Introduction
Thank you for purchasing an XR series remote display. The XR series incorporates the
highest performance standards and the most standard features of any weighing
display, making them the best choice for virtually any remote viewing application.
Like all Avery Weigh-Tronix products, the XR remote displays are designed with
durability, functionality and versatility in mind. If you should need technical assistance,
please contact your local, authorized Avery Weigh-Tronix distributor.
2.1 Display
Figure 2.1 Display samples: Top-XR 4500, Bottom-XR 2000
The weight display is made up of 6 LED digits of 7 segments each. Up to 2 decimal
places can be displayed. (Five decimals on the XR 2000).
ATTENTION! Unauthorized installation and service of this unit may void the
warranty.
