Avidsen V300 - Actuators; Flashing Light; Photocells

EN 20
C - INSTALLATION
6.2 - ACTUATORS
For actuator wiring, use a 2x1.5mm2 section cable and waterproof junction boxes. For each motor, the
cable length must not exceed 8 m.
• Opening inwards:
NBSSPO
CMFV
NBSSPO
CMFV

/
352*
2.


/ / / /


%$7 75$16
*1' *1' 3+2 9 0 0 0 0 ZDUQ ZDUQ %
* actuator installed on the panel that opens rst
6.3 - FLASHING LIGHT
• Connect the ashing light wires to the terminal block as shown in the diagram below and reconnect the
terminal block.
• Use a 2x0.5mm² section cable, at least.
• Maintain the polarity.
L0
PROG
OK
+
-
L1 L2 L3 L4
+
-
BATTRANS
GND GND PHO +24V M1- M2- M1+ M2+ warn- warn+ 2B
6.4 - PHOTOCELLS
• Disconnect the removable terminal block, connect the photocell wires to the terminal block as shown in
the diagram below and then reconnect the terminal block.
1 set of photocells
+
-
BATTRANS
GN
D
GN
D
PH
O
+24V
M1- M2- M1
+
M2
+
warn- warn+
2B
~- ~+ ~+~-NO COM NC
Photocell RX1 Photocell TX1
