EN39
G - TECHNICAL AND LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS
The technical characteristics are provided as an indication only and for a temperature of +20°C. The
company Avidsen reserves the right to modify these characteristics at any time, while under all
circumstances guaranteeing these products’ smooth operation and the type of use intended, in an aim to
improve these products.
Actuators
Type
Power supply
Nominal force
Speed at rated torque
Consumption at rated strength
Assigned operating duration
Cable
Maximum number of cycles/day
Operating temperature
Protection rating
24Vdc motors, reduction gear, type: worm gear
24Vdc
650N
2cm/sec
2A
10 minutes
50cm. 2 x 0.75mm2 section cables
50
-20°C/ +60°C
IP44
Electronic control box
Type
Contents
Power supply
Maximum assigned power
Motor output (- M1 + / - M2 +)
+12Vdc power output (+12V / GND)
Flashing light output (- Warn +)
Photocell input (GND / PHO)
Input for control device (2B / GND)
“2 panels”
Electronic control box for 2 x 24Vdc actuators
1 AVLO electronic card, 1 x 230 / 20Vac transformer
230Vac / 50Hz or 24Vdc
240W
2 outputs for 24Vdc motor
- Maximum output current at start for 3s = 3A.
- Maximum output current after start = 2.5A
To power the photocells. 3.3W maximum
Flashing controlled by the electronic card.
For 24V ashing light with LED only.
Input for dry contact that is normally closed
Input for dry contact that is normally open (closing the contact
triggers a command to set the gate in motion or stop it)
