EN 40
G - TECHNICAL AND LEGAL INFORMATION
TELESCOPIC MOTOR DRIVE KIT
Number of remote control buttons
that can be memorised
Protection fuses
Operating temperature
Protection rating
15 with 1 gate command button and 1 pedestrian command
button
Time-delay fuse in transformer 1A terminal block
-20°C/+60°C
IP44
Flashing light
Type
LED lighting 2.5W max
Flashing controlled by the electronic card
Power supply
Max supply voltage: 24Vdc
Operating temperature
-20°C/ +60°C
Protection rating
IP44
Remote control
Type
Power supply
Buttons
Radiated power
Battery life
Protection rating
Operating temperature
Frequency
Type: OOK AM modulation. 16-bit Rolling code encoder (i.e.
65,536 possible combinations)
433.92MHz
12V via 27A battery
4 keys
< 10mW
-20°C/+60°C
1 years at a rate of 10 x 2s uses per day
IP40 (For indoor use only: home, car or sheltered location)
