EN41
G - TECHNICAL AND LEGAL INFORMATION
TELESCOPIC MOTOR DRIVE KIT
Photocells
Type
Power supply
Maximum assigned power
Output
Transmission angle/Reception angle
Number of connectable photocells
Operating temperature
Protection rating
Range
Contents
Modular infrared beam presence detector. D type safety
system according to EN 12453
1 TX transmitter and 1 RX receiver
12Vdc, 12Vac, 24Vdc, 24Vac
0.7W for the pair
- 1 output with normally closed dry contact (COM/NC)
- 1 output with normally open dry contact (COM/NO)
15m maximum (range may be reduced due to weather
disruption)
10° approx. / 10° approx.
It is possible to connect up to 5 RX receivers in a series
-20°C/+60°C
IP44
