1. Note down the serial number, located on the label on the underside of the device.
2. Use a Phillips #2 screwdriver to remove the four feet from the bottom of the ENVR2 Plus Appliance.
3. Install the left-hand mounting rail to the left side of the rack, and the right-hand mounting rail to the
right side of the rack. Each rail is attached to the front and back of the rack using two of the M5x10L
screws (provided) at each end. Use the upper and lower screw holes, which align with the mounting
holes in the rack unit.
4. Lower the ENVR2 Plus Appliance into place on the rack shelf. Align the screw holes on the sides of the
appliance with the rack shelf mounting holes.
Mounting with the Optional Rack Mount Kit 42
