Mounting with the Optional DIN Rail Mount Kit
Install the ENVR2 Plus Appliance in a location free of dust and particles, vibration, and within the specified
operating temperature range. Otherwise any issues that arise will not be covered by the warranty.
Tip: You may want to mount the appliance before or after you have made all the required
connections depending on where you want to mount the device. See Connecting the Hardware on
page9 for more information on the required connections.
If you are not using the DIN rail mount kit, refer to the instructions for the mounting option you are using:
l
Mounting to the Wall with the Supplied Brackets on page7
l
Mounting with the Optional Rack Mount Kit on page41
Follow these instructions to mount the ENVR2 Plus Appliance with the optional DIN Rail Mount accessory kit
(DIN-ENVR2-8P).
1. Note down the serial number, located on the label on the underside of the device.
2. The bottom of the ENVR2 Plus Appliance has mounting holes for the DIN rail mount. The DIN rail
mount can be mounted in any of the four positions.
3. Use the four M3x5L screws provided to fasten the DIN rail mount to the bottom of the appliance.
Mounting with the Optional DIN Rail Mount Kit 45
