2. To configure a digital output:

a. In the Digital Outputs area, enter a name for the digital output in the Name field.

b. Select the appropriate state from the Circuit State drop-down list.

c. Check the IRCF to Out box to allow the camera's IR Cut Filter to control the external output.

This feature is typically used when the camera is connected to an external IR illuminator. Once

enabled, the IR illuminator is turned on when the camera's IRCut Filter is in monochrome mode.

d. In the Duration field, enter how long the digital output is active for when triggered. You can

enter any number between 100 and 86,400,000 milliseconds.

e. Click Trigger to manually trigger the digital output from the web interface.

f. Click Apply to save your changes.

Washer

On the Washer page, you can activate the washer and wiper sequence to clean the window on H5A

Explosion- Protected bullet cameras. The washer function is supported if these cameras have the optional

washer installed. See the table below for the camera and washer models that support the washer function.

Camera Model Camera Part Number Washer Part Number

H5A Rugged PTZ H5A-RGDPTZ-DP36 AVWASPT0V5L5M00 /

AVWASPT0V23L11M00 /

AVWASPT1V23L30M00 /

AVWASPT3V23L30M00

H5A Explosion-Protected

PTZ

H5EXPTZ-x0-BO30 AVGEX-WASEX2T4AT / AVGEX-WASEX2T4IN

/ AVGEX-WASEX2T4KC / AVGEX-

WASEX2T4GOR

H5A Explosion-Protected

Bullet camera

H5EX-xx-BO1

To activate the washing sequence:

1. Click Washer on the left menu pane.

Select the Enable Washer checkbox.

2. Set the Wiper On Delay to control the amount of time between the washer spray starting and the

wiper function starting.

3. Set the time that the washer will spray in the Washer Period field.

4. Set the time that the wiper function will continue in the Wiper Off Delay field.

5. ClickApply to save your settings.

Tip: We recommend your washing sequence is set up so the Wiper On Delay is at least 4 seconds to

give the washer time to spray the window. The Wiper Off Delay should be at least 8 seconds longer

Washer 31
