MSC SM2S-IMX8MINI 14 / 87
User Manual
Real-time Clock:
• High accuracy RTC
• Optional RTC with temperature compensated DTCXO
Watchdog:
• Module provides a watchdog connected to the SMARC™ connector
Security Device:
• Advanced Security, Safety, and Reliability integrated in the SOC
• Optional Trusted Platform Module 2.0 (TPM): Infineon™ SLB9673 or STMicroelectronics™ ST33TPHF20I2C
Environment Temperature:
• 0° … 70°C (all components commercial temp. or better)
• -40° … 85°C (all components industrial temp.)
• -40° … 85°C (storage)
Environment Humidity:
• 5 … 95% (operating)
• 5… 95% (storage)
*NOTES:
- the second Ethernet interfaces makes use of the PCIe interface, so the PCIe Lane is not available when second Ethernet is populated (mutually exclusive
assembly option)
microSD card socket and Wireless/BT module are mutually exclusive assembly options.
CSI 2-Lane and CSI 4-Lane are mutual exclusive assembly options.
