Figure 7-24. Booting OS (linux) from USB device (pen drive).

7.3.2.5 Available device tree blobs (DTBs)

Table 31. Available DT-blobs.

dtb

comment

msc-sm2s-imx8mm-03N0840E-headless

for 03N0840E variant based headless systems

msc-sm2s-imx8mm-03N0840E-dsi-rm67191

for 03N0840E variant based systems with Raydium RM67191 (1080x1920)

MIPI/DSI panel

msc-sm2s-imx8mm-03N0840E-dsi-avd-tt78qt

for 03N0840E variant based systems with AV Display TT78QT (400x1280)

MIPI/DSI panel

msc-sm2s-imx8mm-03N0880I-headless

for 03N0880I variant based headless systems

msc-sm2s-imx8mm-03N0880I-dsi-rm67191

for 03N0880I variant based systems with Raydium RM67191 (1080x1920)

MIPI/DSI panel

msc-sm2s-imx8mm-03N4200I-headless

for 03N4200I variant based headless systems

msc-sm2s-imx8mm-03N4200I-lvds-am800480n7

for 03N4200I variant based systems with Ampire AMA-800480N7 (800x480)

single channel LVDS panel

msc-sm2s-imx8mm-03N4200I-lvds-ama121a01

for 03N4200I variant based systems with Ampire AMA-121A01 (1280x800)

single channel LVDS panel

msc-sm2s-imx8mm-03N4200I-lvds-p251hvn01

for 03N4200I variant based systems with AUO P215HVN01 (1920x1080)

dual channel LVDS panel

msc-sm2s-imx8mm-03N4210I-headless

for 03N4210I variant based headless systems

msc-sm2s-imx8mm-03N4210I-lvds-am800480n7

for 03N4210I variant based systems with Ampire AMA-800480N7 (800x480)

single channel LVDS panel

msc-sm2s-imx8mm-03N4210I-lvds-ama121a01

for 03N4210I variant based systems with Ampire AMA-121A01 (1280x800)

single channel LVDS panel

msc-sm2s-imx8mm-03N4210I-lvds-p251hvn01

for 03N4210I variant based systems with AUO P215HVN01 (1920x1080)

dual channel LVDS panel

msc-sm2s-imx8mm-13N4200I-headless

for 13N4200I variant based headless systems

msc-sm2s-imx8mm-13N4200I-dsi-tm055jvhg14

for 13N4200I variant based systems with Tianma TM055JVHG14 (720x1280)

MIPI/DSI panel

msc-sm2s-imx8mm-13N4200I-lvds-am800480n7

for 13N4200I variant based systems with Ampire AMA-800480N7 (800x480)

single channel LVDS panel

msc-sm2s-imx8mm-13N4200I-lvds-ama121a01

for 13N4200I variant based systems with Ampire AMA-121A01 (1280x800)

single channel LVDS panel

msc-sm2s-imx8mm-13N4200I-lvds-p251hvn01

for 13N4200I variant based systems with AUO P215HVN01 (1920x1080)

dual channel LVDS panel

msc-sm2s-imx8mm-14N0261I-headless

for 14N0261I variant based headless systems
