AVOCOR F Series User Manual

Revision Date: 1/17/2020
21
No.
Connector
1
OPS USB 3.0
A standard USB connector of the OPS slot for connecting external multimedia player devices.
2
WPS
WPS(HDMI) input for connecting Wireless Presentation sources to the display.
3, 6, 20
Touch USB
Standard, Type-B USB 2.0 ports for connecting touch sources to the display.
4, 7
HUB USB 3.0
Standard USB 3.0 type A connectors for connecting external media, keyboard, keyboard or mouse.
5, 14, 15, 21
HDMI 1, 2, 3, 4
HDCP-compliant HDMI 2.0 digital video input for connecting HDMI sources.
8
SPDIF
Connects external and powered digital speakers or audio receiver/amplifier.
9
Audio Out
Connects external, powered speakers or an external audio receiver/amplifier.
10
IR
Connects an IR Extender cable from this input.
11
Audio In
Connects the audio output from a personal computer here.
12
VGA
Connects components that have RGB or component output jacks, such as a personal computer or
external DTV decoder (a break-out c able is needed for BNC-type connection).
13
HDMI Out
HDCP-compliant HDMI output that will support inputs HDMI 1, HDMI 3, DisplayPort, & WPS.
16
DisplayPort
DisplayPort 1.2 and DisplayPort-HDCP 1.1 compliant, SD/HD input for connecting SDTV, EDTV or HDTV
component video sources.
17
Service Port
A standard USB Type A connector for connecting the USB stick that comes with the package to
upgrade firmware.
18
Touch USB HUB 3.0 in
Type-B USB 3.0 port for connecting touch and media sources to the display for ports 14, 16, 17 & 18.
19
OPS (Open Pluggable Specification) Slot
An optional OPS slot for connecting an internal PC to display 4K content.
22
OPS USB
A standard USB 2.0 connector of the OPS slot for connecting external multimedia player devices.
23
HUB USB
Standard USB 2.0 type A connectors for connecting external media, keyboard, keyboard or mouse.
24
LAN
An RJ-45 connector for interfacing with a PC or home theater automation/control system via a Cat
5 cable.
25
RS232C
A female, 9-pin D-sub connector for interfacing with a PC or home theatre automation/control
system.
