AVOCOR F Series User Manual

Revision Date: 1/17/2020
58
7. Specifications
Table 7-1 lists the signal types supported by each input on the AVF-6550 display.
PANEL
Diagonal Size (Inch)
65”
Backlight
Direct LED
Aspect Ratio
16:9
Input Resolution
3840 x 2160 @ 60 Hz
Response Time
8 (ms)
Brightness
370 (cd/m
2
)
Contrast Ratio
4000:1
Viewing Angle
178º (H) / 178º (V)
Supported Colors
1.07 billion colors
Display Orientation
Landscape compatible
TOUCH SYSTEM
Interface
Touch USB
Touch
High-resolution inGlass™ touch; Up to 20 points
Glass
Chemically strengthened glass with G2&AF finish;
0.1-inch/2mm thickness
Supported Operating System
Windows 7 / 8 / 10; Mac OS 10
AUDIO
Built-in Speakers
4 KΩ / 2 x 15W
CONNECTIVITY
Connections
5x HDMI 2.0 / 1 x VGA / 1 x DisplayPort 1.2 / 1 x HDMI Out
Audio
Audio In / Audio Out / SPDIF Out
Control
1x Touch USB 3.0 HUB / 3 x Touch USB 2.0 / RS232 / Ethernet
PHYSICAL SPECIFICATIONS
Dimensions
61.8 x 36.2 x 3.8 (in) / 1,569 x 919.2 x 95.5(mm)
Weight
Net: 46.5 kg / Gross: 58.5 kg
Wall Mount
23.6 x 15.7 (in) / 600 x 400(mm)
MiniPC Mount
75 x 75, 100 x 100 (mm) / 2.9 x 2.9, 3.9 x 3.9 (in)
Fanless Design
Yes
OSD FUNCTIONS
OSD Languages
English, French, German, Dutch, Danish,
Italian, Swedish, Portuguese, Spanish
Source Auto Detect Function
Yes
POWER
Power Supply
AC100-240V (Worldwide), Max 3.7A, 50/60Hz
Maximum Power Consumption
200 W (w/o OPS module)
Standby
≦0.5 W
ENVIRONMENTAL
Operating Temperature
0 °C ~ 40 °C
Storage Temperature
-20 °C ~ 60 °C
Humidity
35% ~ 85%
