AVOCOR F Series User Manual

Revision Date: 1/17/2020
51
Command and Response Examples
Here are some examples of Hexadecimal serial commands and their responses:
Table 6-1. Serial Command/ Response Examples
Description
Command sent to LCD Panel
Response Received from LCD Panel
Turn LCD panel power off.
07 01 02 50 4F 57 00 08
07 01 00 50 4F 57 00 08
Turn LCD panel power on.
07 01 02 50 4F 57 01 08
07 01 00 50 4F 57 01 08
Request LCD panel power status.
07 01 01 50 4F 57 08
07 01 00 50 4F 57 XX 08
(XX = 0 when off or 1 when on)
Set the LCD panel contrast to 30
(1E hex).
07 01 02 43 4F 4E 1E 08
07 01 00 43 4F 4E 1E 08
Reset the LCD panel display settings.
07 01 02 41 4C 4C 00 08
07 01 00 41 4C 4C 00 08
Request LCD panel serial number.
07 01 01 53 45 52 08
07 01 00 53 45 52 S(0)…S(12) 08
S(0) …S(12) = the serial number in ASCII
Request LCD panel firmware version.
07 01 01 47 56 45 08
07 01 00 47 56 45 S(0)…S(5) 08
S(0)…S(5) = the firmware version in ASCII
Serial Command List
Table 6-2 lists all supported commands.
Table 6-2. Serial Commands
Main Item
Control Item
Type
CMD
(HEX)
Value
(HEX)
Reply
(HEX)
Content
CMD
(ASCII)
Power Control and
Input Source
Power Control
W/R
50 4F 57
0
0
Off (soft power)
POW
1
1
On (soft power)
Signal State
R
50 4F 53
-
0
Signal
POS
-
1
No signal
IPC Control
W/R
49 50 43
0
0
Off
IPC
1
1
On
OPS Power State
W/R
4F 41 50
0
0
Follows display
OAP
1
1
Always on
Input Source
W/R
4D 49 4E
0
0
VGA
MIN
9
9
HDMI 1
0A
0A
HDMI 2
0B
0B
HDMI 3
0C
0C
HDMI 4
0D
0D
DisplayPort
0E
0E
IPC/OPS
13
13
WPS
Display Adjustment
Display Adjustment
W/R
42 52 49
00~64
00~64
Back Light Brightness
BRI
W/R
42 52 4C
00~64
00~64
Digital Brightness Level
BRL
W/R
42 4C 43
0
0
Off (Back Light)
BLC
1
1
On (Back Light)
W/R
43 4F 4E
00~64
00~64
Contrast
CON
W/R
48 55 45
00~64
00~64
Hue
HUE
W/R
53 41 54
00~64
00~64
Saturation
SAT
W/R
4E 4F 52
0
0
Noise Reduction: Off
NOR
1
1
Noise Reduction: Low
2
2
Noise Reduction: Medium
3
3
Noise Reduction: High
W/R
55 53 52
00~64
00~64
Red Gain (mapping
0~100)
USR
