AVOCOR F Series User Manual

Revision Date: 1/17/2020
52
Main Item
Control Item
Type
CMD
(HEX)
Value
(HEX)
Reply
(HEX)
Content
CMD
(ASCII)
Display Adjustment
Display Adjustment
W/R
55 53 47
00~64
00~64
Green Gain (mapping
0~100)
USG
W/R
55 53 42
00~64
00~64
Blue Gain (mapping
0~100)
USB
W/R
55 4F 52
00~64
00~64
Red Offset (mapping
0~100)
UOR
W/R
55 4F 47
00~64
00~64
Green Offset (mapping
0~100)
UOG
W/R
55 4F 42
00~64
00~64
Blue Offset (mapping
0~100)
UOB
W/R
43 4F 54
0
0
User
COT
1
1
6500K
2
2
9300K
6
6
5000K
7
7
7500K
W/R
47 41 43
0
0
Gamma Off
GAC
1
1
Gamma 2.2
VGA
Adjustment
W/R
50 48 41
00~FF
00~FF
Phase
PHA
W/R
43 4C 4F
00~64
00~64
Clock
CLO
R/W
48 4F 52
00~64
00~64
Horizontal Position
HOR
R/W
56 45 52
00~64
00~64
Vertical Position
VER
W
41 44 4A
0
0
Auto Adjust
ADJ
Sharpness
W/R
53 48 41
00~64
00~64
Sharpness
SHA
Other Control
Scaling
W/R
41 53 50
0
0
Main Window Aspect
Ratio
Native (PointToPoint)
ASP
1
1
Full Screen (16:9)
2
2
Pillarbox (4:3)
3
3
Letterbox
4
4
Auto
W/R
5A 4F 4D
00~0A
00~0A
Adjust overscan ratio
ZOM
Baudrate
Adjustment
W/R
42 52 41
0
0
115200
BRA
1
1
38400
2
2
19200
3
3
9600
Other Control
W
52 43 55
0
0
MENU Key
RCU
1
1
INFO Key
2
2
UP Key
3
3
DOWN Key
4
4
LEFT Key
5
5
RIGHT Key
6
6
OK Key
7
7
EXIT Key
8
8
VGA Key
0A
0A
HDMI1 Key
0B
0B
HDMI2 Key
17
17
SCALING Key
18
18
FREEZE Key
19
19
MUTE Key
1A
1A
BRIGHT Key
1B
1B
CONTRAST Key
1C
1C
AUTO Key
1D
1D
VOLUME+ Key
1E
1E
VOLUME- Key
