HARDWARE OVERVIEW
1
17
1. HARDWARE OVERVIEW
1.1 Front Panel
Note: The functions on the front panel may vary, depending on the mode you have.
1) Select & Unlock
These two buttons are used to unmount a hard disk. Press Select and check the HDD indicator (red &
always on) to ensure the hard disk you want to unmount is chosen. Then, choose Unlock to unmount the
hard disk (HDD indicator: red & flashing).
When the hard disk unmount is completed, the indicator will be off, and you’re ready to remove the hard disk
from the HDD tray.
2) HDD Indicators
Check the HDD indicator for each installed hard disk to ensure the hard disks work normally.
Note: Some statuses are for selected models only.
Color Status Meaning
-- No light No hard disk is installed, or the installed hard disk is not detected. Please install a hard disk
or replace the installed hard disk, and try again.
Green Always on The installed hard disk is detected well.
Green Flashing Data reading / writing.
Red Always on The hard disk is selected for unmounting.
Red Flashing The device is mounting or unmounting the selected hard disk.
3) Status LED indicators
Press to power on the device; press and hold for 3 seconds to power off the device.
Note: Some indicators are for selected models only.
This device is power-supplied.
The device is connected to Internet.
The device is connected to LAN.
An alarm event occurs.
Any of the adapter, power or fan is abnormal.
Video playback is on.
eSATA An external disk array is connected.
An USB flash drive or USB hard disk is connected.
This device is in the standby mode when its powered off.
4) Power ( )
Press to power on the device; press and hold for 3 seconds to power off the device.
5) Mouse port ( )
Insert a mouse for function operation.
6) USB port ( )
Insert a compatible USB flash drive for video backup.
Note: For the compatible list of USB flash drives, please refer to “APPENDIX 3 COMPATIBLE USB FLASH
DRIVE LIS” at page 75.
