6.11.4 LOCAL ALARM IN
Note: This function is available for the models which support alarm-in connection to the recorder itself.
Please check the specifications of your recorder to know if your recorder supports this function.
This function is used when the external alarm-in device is connected directly to the recorder. You can configure
how the alarm device should work by choosing N.O. or N.C.
LOCAL ALARM IN
CHANNEL TITLE ALARM IN
CH1 N.C.
CH2 N.O.
CH3 OFF
CH4 OFF
6.12 MAINTAIN
6.12.1 SYSTEM
SYSTEM
BACKUP CONFIG SUBMIT
RESTORE CONFIG SUBMIT
RESET DEFAULT SUBMIT
DEVICE TITLE nvr_1
ENABLE AUTO PLUG AND PLAY ON
BIND MAC ADDRESS OFF
RESET ALL GUARD CONNECTION SUBMIT
1) BACKUP CONFIG / RESTORE CONFIG
To save the current configurations for later use, such as restoring after the recorder upgrade or applying to
another recorder, insert a compatible USB flash drive into the USB port, and select SUBMIT in SUBMIT in
BACKUP CONFIG to copy the current configurations to a file “System.bin” and save to your USB flash
drive.
To restore the configurations, insert the USB flash drive including “System.bin” to the USB port, and select
SUBMIT in RESTORE CONFIG.
2) RESET DEFAULT
Click SUBMIT to reset all settings or partial settings to their factory default values, and select YES to
confirm or NO to cancel. The system will reboot after reset.
3) DEVICE TITLE
Enter a title for this device.
4) ENABLE AUTO PLUG AND PLAY
Switch to ON to allow the camera to be detected and configured automatically when it’s connected to this
device.
Note: This function is available only when the brand of the cameras connected is the same as this
device.
5) BIND MAC ADDRESS
This function is recommended to be used when your surveillance system is more than 256 cameras. It would
be helpful for the system to get the address of each connected camera quickly if the system accidentally
shuts down and needs to recover.
