AXIS 231D - Installing the AXIS 231D
Manual Installation using AXIS IP Utility
Follow these instructions to set the IP address manually using AXIS IP Utility:
1. Acquire an unused IP address for your
AXIS 231D. (AXIS IP Utility detects the
subnet your computer is connected in.
The AXIS 231D must be installed on the
same subnet).
2. Connect a standard RJ-45 network cable
to your AXIS 231D and connect it to the
network.
3. Connect the power to the AXIS 231D.
4. Start AXIS IP Utility on your computer.
5. Enter the serial number:
6. Enter the IP address acquired for your AXIS 231D and click Set IP.
7. When prompted by AXIS IP Utility, restart the Network Dome Camera by
disconnecting and reconnecting the external power supply.
8. A message confirming that the IP address has been set will be displayed, click OK.
9. Click View Home Page to access the AXIS 231D Web pages.
10.Enter a new password for the root user (administrator).
11.If required, accept the installation of AMC onto your workstation. See AXIS Media
Control (AMC), on page 10 for more information.
12.The installation is now complete, proceed to Using the Network Dome Camera, on
page 15.
AXIS IP Utility is a Windows software application that installs the AXIS 231D to your local net-
work using a static IP address.
•Download the AXIS IP Utility software to your computer, free of charge from the Support
pages at http://www.axis.com/techsup/software
•Double-click the setup.exe file and follow the on-screen instructions to install the software
on your computer.
The serial number/MAC address (S/N) is located on the label on the AXIS 231D
