6 USER MANUAL
_________________________________________________________________________________________________________________
Balances AD6:
1 – pan
2 – pan support
(under the pan)
3 – pan ring
4 – LCD display
5 – keys
6 – rotating legs
7 – water level
Rear view:
7
6
1
2
4
5
ON
OFF
Adjust switch
RxD (receiver)
TxD (transmitter)
gnd
chassis
RS232C
Feeder
Feeder Printer or computer
1
2
3
4
5
6
7
8
9
~230V
