Troubleshooting
Problem
CauseSolution
Youareusinganoldversionof
AXISIPUtility.
UpgradetoAXISIPUtility
version4.14orlater.
Systemcontrolleristurnedoff.Connectthesystemcontroller
tothepowersupply.
SystemcontrollerCan'tndsystemcontrollerin
AXISIPUtility.
Systemcontrollerisnot
connectedcorrectlytothe
network.
Connectthesystemcontroller
tothenetwork.
Contentdestinationis
unavailable.
Checkthecontentdestination
statusontheDashboardon
page23inAXISBodyWorn
Manager.
Manysimultaneousofoads
affecttransferspeed.
OpenthedeviceinAXISBody
WornManagertocheckthe
transferstatus.Waitfor
recordingstobetransferred.
Transferstatushistoryis
displayedforthreedaysafter
thetransferiscomplete.
Camerawasundockedbefore
thetransferoftherecording
wascompleted.
OpenthedeviceinAXIS
BodyWornManagertocheck
thetransferstatus.Dock
thecameraandwaitforall
recordingstobetransferred.
Transferstatushistoryis
displayedforthreedaysafter
thetransferiscomplete.
Thetimeinthebodyworn
systemdoesn'tmatchthetime
ofthecontentdestination.
Makesurethatthebody
wornsystemandthecontent
destinationhavematching
time.
Recordingsdon'tappearin
contentdestination.
Outoflicenses.Checklicensesandbuy
additionallicensesifneeded.
Recordingshavethewrong
resolution.
Theimageresolutionsetting
inAXISBodyWornManager
iswrong.
Gotothecameraprolein
AXISBodyWornManager
andsetthecorrectimage
resolution.
Recordingisdeleted.Retentiontimeofthecontent
destinationisshort.For
example:Iftheretentiontime
onthecontentdestinationis
7days,andtherecordingon
thecamerais8daysoldwhen
docking,thentherecording
willbedeletedwhenitreaches
thecontentdestination.
Changetheretentiontimeon
thecontentdestinationtoa
highervalue.
Recordingistransferredfrom
cameratosystemcontroller,
butnotfromthesystem
controllertothecontent
destination.
Thecamerahasbeenremoved
fromthecontentdestination.
Renametheuserthatthe
cameraisassignedto,and
restartthesystemcontroller.
Contentdestination
Connectionbetweenthebody
wornsystemandthecontent
destinationislost.
Certaincongurations,suchas
theIPaddressofthecontent
destinationwerechanged.
Changeconnectionleon
page25
50

Axis W101 Specifications

General

Sensor type	CMOS
Night vision	-
Fixed focal length	21 mm
Maximum frame rate	30 fps
Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/32000 - 1/25 s
Minimum illumination	0.1 lx
Vertical field of view	82 °
Viewing angle, horizontal	141 °
Battery capacity	3600 mAh
Power source type	USB
Battery life (max)	17 h
Accelerometer	Yes
Certification	EN 55032 Class B, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), RCM AS/NZS CISPR 32 Class B EN 300328, EN 301489-1, EN 301489-17, EN 303413, FCC Part 15 Subpart C, RSS-247 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC/EN 60529 IP67 MIL-STD-810H (Method 501.7, 503.7, 505.7, 509.7, 512.6, 516.8)
Video compression formats	AVC, H.264, MPEG4
Housing color	White
Housing material	Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 45 °C
Operating temperature (T-T)	-20 - 55 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 100 %
Connectivity technology	Wireless
Internal storage capacity	64 GB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	94 mm
Weight	179 g
