Axon Fleet 3 Installation Guide
Axon Enterprise, Inc. Page 29 of 47
• Door Triggers are applied one trigger per door. Axon SKU 71210 (US) or 71211 (UK)
includes the trigger with wiring, screw, and magnet.
2. If a brake Signal input will be used, wire brake power to the Power and Signal Harness
cable using the following guidelines:
• Note that brake Signal inputs are only supported on Hub input numbers 13 and 14.
• If available, connect the brake sense output from vehicle upfitter harness to the Hub
input harness.
• If an upfitter harness is not available in vehicle, connect to an alternate +12V brake
source, such as the brake light.
Use a poke and wrap connection only so there is no interference with the integrity of
the original circuit. Using butt splices or T-taps may introduce a failure point.
Axon Signal Vehicle Device Connections
If an Axon Signal Vehicle (ASV) will be used to activate Axon Body-Worn Cameras, use the
ASV Fleet 3 cable assembly (Axon SKU 70117) to connect the Fleet 3 Power and Signal
Harness.
Note: In previous Axon Fleet versions, the Fleet Power Units and the Axon Signal Vehicle device may
have been mounted in separate areas. Since all 12V inputs will run to both Hub and Axon Signal
Vehicle device, it may be necessary to extend the wires to Hub mounting location.
1. Route the male end connector of the ASV Fleet 3 cable assembly to the mounting
location of ASV device.
2. Remove the screw terminal interface on the ASV device, which will reveal the female
connector.
3. Plug the male connector end of the ASV Fleet 3 cable assembly into the female connector
on the ASV device.
Camera Ethernet Cables
Use provided Power Over Ethernet cables (SKU 72032) for camera connection. The cables
are 20 feet long (6 meters) CAT6 rated with a custom over-mold to enhance connection
integrity.
1. Route a Power Over Ethernet (POE) cable from each of the camera mounting locations to
the Hub mounting location using the following guidelines:
To Next Page
