11-4
Chapter 11. SPECIFICATIONS
z
Loader communication
Transmission line: 3-wire method
Transmission speed: Fixed at 19200 bps.
Recommended cable: Included with the SLP-C35J50.
z
Isolation between input and output
Portions enclosed by solid lines are insulated from other signals.
Power supply Control output 1
PV input Control output 2
CT input 1 Internal circuit
CT input 2 Event output 1 *
Loader communication Event output 2 *
Digital input 1 Event output 3
Digital input 2
RS-485 communication
Whether or not inputs and outputs are provided may vary depending on the model.
* In case of the independent contacts, the output 1 and the output 2 are isolated.
z
Environment conditions
z Standard conditions
Ambient temperature: 23±2 °C
Ambient humidity: 60±5 %RH
Power supply voltage: AC power model, 105 V AC±1 %, 50/60 Hz±1Hz
DC power model, 24 V AC±1%, 50/60 Hz±1Hz
24 V DC±5 %
Vibration: 0 m/s
2
Shock: 0 m/s
2
Mounting angle: (Reference plane) ±3°
z Operating conditions
Ambient temperature: 0 to 50 °C (0 to 40 °C for tight-mounting)
Ambient humidity: 10 to 90 %RH (No condensation)
Power supply voltage: AC power model, 85 to 264 V AC, 50/60 Hz±2 Hz
(Rating: 100 to 240 V AC, 50/60 Hz)
DC power model, 21.6 to 26.4 V AC, 50/60Hz±2Hz/21.6 to 52.8V DC
(Rating: 24 V AC, 50/60 Hz/24 to 48V DC)
Vibration: 0 to 2 m/s
2
(10 to 60 Hz for 2 h in each of the X-, Y-, and Z-direction)
Shock: 0 to 10 m/s
2
Mounting angle: (Reference plane) ±10°
z Transportation conditions
Ambient temperature: -20 to +70 °C
Ambient humidity: 10 to 95 %RH (No condensation)
