Azbil C15 User Manual

11-5
Chapter 11. SPECIFICATIONS
z
Other specifications
Degrees of protection: Front panel of the unit conforms to IP66/NEMA 4.
(Individual panel mounting with attached gaskets)
(NEMA4: Equivalent, but non-UL certified)
Power consumption: AC power model, Max. 12 VA (8 VA at 100 V AC and 12 VA at 264 V AC)
(When using the functions similar to those of Azbil Corporation’s C10,
the power consumption is 6 VA at 100 V AC and 9 VA at 264V AC.)
DC power model, Max. 7 VA (24 V AC), Max. 5 W (24 to 48 V DC)
Altitude: 2000 m or less
Insulation resistance: Between power supply terminal and secondary terminal, 500 V DC,
10 MΩ or more
Dielectric strength: AC power model, Between power supply terminal and secondary
terminal, 1500 V AC for 1 min.
DC power model, Between power supply terminal and secondary
terminal, 500 V AC for 1 min.
Inrush current at power ON: AC power model, Max. 20 A
DC power model, Max. 20 A
Non-detected power
failure time: Max.20 ms (AC model)
No power failure allowed (DC model)
Mass: Panel mounting type Approx. 150 g (including mounting bracket)
Socket mounting type Approx. 200 g (including socket)
Terminal screw tightening
torque: Panel mounting type 0.4 to 0.6 N·m
Socket mounting type 0.78 to 0.98 N·m
Applicable standards: CE; EN61010-1, EN61326-1 (For use in industrial locations)
During EMC testing, the reading or output may fluctuate by ±10%FS.
Over-voltage category: Category II (IEC60364-4-443, IEC60664-1)
Allowable pollution degree: Pollution degree 2
Decoration sheet
material/color: Polyester film/Dark gray (DK546)
Case material/color: Reformed PPE/Light gray (DIC650)

Accessories
Name Model No.
Mounting bracket (for C15T) 81409651-001
Gasket 81409657-001

Optional parts
Name Model No.
Mounting bracket (for C15T) 81446403-001
Gasket (20) 81406918-001
Current transformer (800 turns, 5.8 mm hole dia.) QN206A*
Current transformer (800 turns, 12 mm hole dia.) QN212A*
Socket (for C15S) 81446391-001
Hard cover 81446442-001
Soft cover 81446443-001
Terminal cover 81446898-001
Smart Loader Package SLP-C35J50
L-shaped plug adaptor 81441057-001
* Not UL-certified.
