5-4
Chapter 5. ADVANCED OPERATION
Display Item Item Description Setup Item and Description
Factory
Setting
Remarks
C-06
Analog output
type and range
selection
0: 0 to 5 V instantaneous flow
rate output
1: 1 to 5 V instantaneous flow
rate output
2: 0 to 20 mA instantaneous
flow rate output
3: 4 to 20 mA instantaneous
flow rate output
4: 0 to 5 V setting flow rate
output
5: 1 to 5 V setting flow rate
output
6: 0 to 20 mA setting flow rate
output
7: 4 to 20 mA setting flow rate
output
0 The scale can also be changed to the
desired flow rate range.
For details,
C-28 (Optional
analog scaling function)(P.5-8).
*2
,
*3
C-07
Event output 1
type assignment
0: Not used (OFF at all times)
1: ON when the totalized flow
event occurs
2: Totalized pulse output
3: ON when the flow rate is OK
4: ON in control mode
5: ON in fully open mode
6: ON in control or fully open
mode
7: ON in fully closed mode
8: PV upper limit event
9: PV lower limit event 1
10: PV lower limit event 2
-1 to -10: Inverse output of
above 1 to 10
(Normal operation: ON,
Event occurrence: OFF)
0 The event output delay time is set
in the parameter setup mode (
P.5-11).
Note, however, that delay cannot be
set for totalizer pulse output.
9: Events are output even in fully
closed operation mode.
10: Events are not output in fully
closed operation mode.
-1 to -10: OFF at all times during
power shutoff
C-08
Event output 2
type assignment
0
C-09
External 3-way
switching function
0: Not used
1: Switching of operating mode 1
2: Switching of SP No.
3: Switching of totalizing
operation
4: Switching of analog I/O
voltage range
(simultaneous external
switching of C-05 and C-06)
5: Switching of operating mode 2
0 External inputs OPEN/GND/5V are
switched as shown below.
1: Control/fully closed/fully open
2: SP-0/SP-1/SP-2
3: Continue count/reset count/stop
count
4: See the table in note
*3
(page 5-10).
0 to 5 V/0 to 5 V/1 to 5 V
5: Fully closed/control/fully open
To Next Page
