Chapter 7. SPECIFICATIONS
z
Model with separate display
MQV9005C/9020C/9200C/9500C/0002C/0005C/0020C/0050C
• Main unit Unit: mm
37
2-9/16-18UNF
44
2281
18.5
15.5
(141.4)
Rc 1/4" pipe coupling (2)
23.523.5
(25.7) (25.7)
(137)
HEX21
HEX9/16
Rc 1/4" connection type
9/16-18UNF connection type
1/4" Swagelok connection type
130
90
102
35
14
M4 screw (2) depth 5 min.
(137.8)
(23.9)
(23.9)
1/4" VCR connection type
SS-4-VCR-1-00032SC11
7.3
18
Pipe coupling made by Swagelok (2)
Jack for
loader
150±2
30±0.5 30±0.5
11±0.5
15±0.5
outside diameter 1/4",
material SUS316
SS-400-1-6ST
Applicable pipe:
