ADSL2+ Ethernet USB Combo Router – Easy Start
1.4 Typical ADSL Router Connection
Fig 1-6 below shows a typical single user connection.
Computer/Notebook
with Ethernet Network
Card or USB Port
Ethernet / USB
Cable
Figure 1- 6 :Single User Connection Diagram
To connect to multiple computers/notebooks, you may further expand one of the Ethernet Ports
via an Ethernet Hub/Switch. For details on how to connect to the Ethernet Switch/Hub, please
refer to the documentation that comes with the unit. See Fig 1-7.
Computer/Notebook with
USB Port
USB
Computer/Notebook with
Ethernet Network Card
Figure 1-7 : Multiple PCs Connection
