Aztech DSL600E User Manual

ADSL2+ Ethernet USB Combo Router – Easy Start
1.3.3 Front Indicators (Ethernet Router)
Fig 1-4 shows the front indicators of the Ethernet Router.
3
2
1
Figure 1-4 : Front Indicators (Ethernet Router)
Label Description
1 PWR
Lights up when power is supplied to the Router.
2 DSL
Lights up when the ADSL connection is established.
Flickers when the ADSL Router is trying to establish a connection with
the ADSL Service Provider.
3 ETH/ACT
Lights up when the Ethernet cable is properly connected from your
ADSL Router to the Ethernet Card.
Page 9 of 42
