ADSL2+ Ethernet USB Combo Router – Easy Start
1.2 ADSL Router Package
Fig 1-1 below shows the ADSL Router Package. For any missing items, please contact your
dealer immediately.
ADSL Router Utility CD Easy Start Manual
Page 6 of 42
USB Cable Telephone Cable (RJ11) CAT-5 UTP Straight Ethernet
(For Ethernet USB Network Cable (RJ45)
Combo Router only)
POTS-Splitter (Optional) Power Adapter (DC 9V)
Figure 1-1 : ADSL Router Package
Depending on your country of purchase, your package may or may not come with a POTS
Splitter. The POTS Splitter is required if you are connecting a Telephone Set to the Ethernet
Modem. Please refer to Chapter 2 Section 2.2 - Connecting to the ADSL Line for details.
POTS-Splitter can also be purchased from your dealer.
