Service Program
3
3 - 12 Perfusor® compact, 2.1 gb
Alarm Tone
1. Switch on unit.
2. Insert syringe and confirm (or select), e.g. OPS 50 ml.
3. Enter rate and actuate the Start button to start delivery.
4. Open syringe holder, an alarm is triggered.
5. Compare the alarm tone with the settings:
- For units with unit software up to PLAA00063.3
(Service Program version 55004):
0 = continuous tone with 3 Hz intermittent
1 = continuous tone, static
2 = continuous tone with modulation 2.4 kHz
3 = continuous tone with modulation 4.8 kHz
- For units with unit software up to PLAA00070.0:
(Service Program version 6.001)
Continuous tone with 3 Hz intermittent
Continuous tone, static
Syringe / Syringe Selection
Note
Note down the current code for 20 ml and 50 ml syringes before
starting the test.
Test for table or internal setting:
1. Open holder, then press keys 7 C X X F and 7 C Y Y F
The syringe is accepted (if an alarm is triggered, then the sy-
ringe selection is not correct!).
2. If a free type was input but is not accessible, then you should
check in addition:
Press keys 7 C {number of the 20 ml free type} F and keys 7
Test Code 20 ml Test Code 50 ml
Wildcard in the sub-
sequent text
XX YY
up to unit number
50920
21 51
from unit number
50921 on
24 61
Table 3 - 1
