Parameter Descriptions 7-3MN762
Number
Name
(Display Level)
Value Range, Description and Preset Value
P-08 Speed Reference Source Range: 0-12
Preset: 0
Sets the digital inputs conguration. The operation of P-08 changes depending
on the value of P-07. Refer to Table 8-1, Table 8-2, Table 8-3, and Table 8-4.
P-09 Stop Mode Range: 0 to 2
Preset: 0
0: Ramp to stop (power dip ride-through). If input power is lost the drive will use
regen power to reduce the motor speed.
1: Coast to stop. The transistor power device drivers are turned off and motor
coasts to stop (no braking).
2: Ramp to stop (fast stop). Uses deceleration ramp when input power is lost
or uses constant power braking mode for normal braking.
If the supply is lost and P-09=0 the drive will try to continue running by reducing
the speed of the load using the load as a generator.
If the supply is lost and P-09=2, the drive will ramp to stop using the P-33 decel
ramp. Also activates constant power braking mode for normal braking.
P-10 Accel Time Range: 0 to 600.0 seconds
Preset: 5.0
Sets the time for the motor to accelerate from 0 to motor rated speed (P-03).
Short times may cause over current trips.
P-11 Decel Time Range: 0 to 600.0 seconds
Preset: 5.0
Sets the time for the motor to decelerate from motor rated speed (P-03) to 0.
Short times may cause over voltage trips. When set to 0, drive will decel as fast
as possible without tripping.
P-12 Preset Speed 1 Range: -P-06 to P-06
Preset: 0.0
Sets the value of Preset Speed 1. Range is -P-06 (reverse) to + P-06.
P-13 Preset Speed 2 Range: -P-06 to P-06
Preset: 0.0
Sets the value of Preset Speed 2. Range is -P-06 (reverse) to + P-06.
P-14 Preset Speed 3 Range: -P-06 to P-06
Preset: 0.0
Sets the value of Preset Speed 3. Range is -P-06 (reverse) to + P-06.
P-15 Preset Speed 4 Range: -P-06 to P-06
Preset: 0
Sets the value of Preset Speed 4. Range is -P-06 (reverse) to + P-06.
P-16 Speed Reference Scaling Range: 0 to 500.0%
Preset: 100.0
Sets the parameter value in % of full scale. Normally, the max speed reference
(P-06) is 10 VDC or 20mA. P-16 adjusts the speed reference to another value (for
example, 9.5 VDC or 19mA). If P-07 = 1 or 2, this parameter adjusts the keypad
reference and an Analog Reference.
Table 7-1 Parameter Descriptions Continued
