1.19 Appendix A. Specific Camera / Sensor Data 211
1.19.2.4.4.3 Gray scale version
Device Feature And Property List (p. 211)
1.19.2.4.5 Device Feature And Property List
• mvBlueFOX-202bG Features (p. 211)
• mvBlueFOX-202bC Features (p. 211)
1.19.2.4.5.1 mvBlueFOX-202bG Features
1.19.2.4.5.2 mvBlueFOX-202bC Features
1.19.2.5 mvBlueFOX-[Model]202d (1.2 Mpix [1280 x 960])
1.19.2.5.1 Introduction
The CMOS sensor module (MT9M034) incorporates the following features:
• resolution to 1280 x 960 gray scale or RGB Bayer mosaic
• supports window AOI mode with faster readout
• programmable analog gain (0..12 dB)
• progressive scan sensor (no interlaced problems!)
• high dynamic range (p. 141) 115 dB (with gray scale version)
• rolling shutter
• programmable readout timing with free capture windows and partial scan
• many trigger modes (free-running, hardware-triggered)
