1.9 Technical Data 57
Figure 27: Output switching times
Characteristics Symbol Test conditions Typ. Unit
Turn-On time t
ON
R
L
= 100 Ohm, V
CC
10V, I
C
= 2mA
3
us
Storage time t
S
3
Turn-Off time t
OFF
3
Turn-On time t
ON
R
L
= 1.9 kOhm, V
CC
5V, I
C
= 16mA
2
us
Storage time t
S
25
Turn-Off time t
OFF
40
Comment Min Typ Max Unit
I
on
load current 15 mA
I
off
leakage current 10 uA
V
on
Sat. at 2.4 mA V
IH
0 (0.←-
2)
0.4 V
V
off
30 V
1.9.4.3 LED states
State LED
Camera is not connected or defect LED off
Camera is connected but not initialized or in "Power off" mode. Orange light on
Camera is connected and active Green light on
1.9.4.4 Assembly variants
The mvBlueFOX-MLC is available with following differences:
• Mini-B USB connector and digital I/O pin header
– 1/1 opto-isolated or 2/2 TTL compliant digital I/O
• USB via header without Mini-B USB connector
• female board connector instead of pin header (board-to-board connection)
• 3 different S-mount depths
