1.9 Technical Data 43
State LED
Camera is not connected or defect LED off
Camera is connected and active Green light on
1.9.2.3 Components
• FPGA for image processing
• pixel clock up to 40 MHz
• reliable image transfer
– using bulk-mode
– image data surrounded by headers
• several trigger modes
– auto, SW, external
• flash control output
– using opto-isolated outputs
• opto-isolated I/O
– 2 inputs, 2 outputs on D-Sub 9 connector
• bus powered
– no external power supply needed
• two USB connectors
– standard USB or circular plug-in connector 4 pin locked
• ambient temperature operation: 0..45 deg C / 30..80 RH
• ambient temperature storage: -20..60 deg C / 20..90 RH
Additional features of mvBlueFOX-2xx:
• 8 Mega-pixel image memory (FiFo)
• new ADC
• 10 Bit mode
MATRIX VISION GmbH
