8. Light processor assembly

Image 8-11

Light processor installation

4. Secure the light processor assembly by fastening both captive screws (1 & 2 ).

5. Fixate the co rner bracket to the projector frame with an hexag on head screw (3).

R5905043 DP2K-12C/11CX 19/02/2018

145
